ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
主要特点
Stainless steel structure;Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
重量反馈和比例跟踪摆脱了不同材料的不同比例的可变包装重量的不足。
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Data
Hopper | Quick disconnecting hopper 25L |
包装重量 | 10 - 1000g |
包装精度 | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
填充速度 | 5 – 20 times per min |
电源 | 3P AC208-415V 50/60Hz |
总功率 | 2.25Kw |
总重量 | 350公斤 |
Overall Dimensions | 1205×1010×2174mm |
