Brief Introduction:
10-20kg Rice Packing Machine
This machine is suitable for the pillow or gusset sealing bag of rice, beans, sugar, corns. This Rice Packaging Machine is equipped with 2 heads linear weigher.
This vertical rice packing machine unit including of one two head linear Weighing Machine, one 立式填充密封机, one platform and one Inclined Bucket Conveyor. It integrates the functions of feeding, metering, bag-making, packaging, sealing, printing, punching and countering, has automatic film position control function, both the horizontal sealing and film pull mechanisms adopt servo motor for transmission so as to guarantee high efficiency of the machine. It could be ideally combined with the other machines.
The machine can pack two type of bag, gusset bag and pillow bag. It can second time film pulling function and do max bag length is 920MM.
特征:
High speed: Around 10-30 bags/min(according to different weight).
操作方便:PLC控制器和彩色触摸屏,触摸屏故障指示。
易于调整:仅需约10分钟即可更换不同的袋子。
频率控制:速度可在该范围内通过频率转换进行调节。
高自动化:在称重和包装过程中无人值守,故障时机器自动报警。
安全和卫生:
没有胶片,机器会报警。
机器报警并在气压不足时停止。
安全开关,安全开关,机器报警和安全防护装置打开时停止的安全防护装置。
卫生结构,产品接触部位均采用sus304不锈钢。
应用:
This rice packing machine is suitable for granule products, Such as grains, rice, dried fruits, beans, nuts, salt, sugar, tea, seeds, detergent powder, etc. So this machine can also be designed as Beans Packing Machine and Sugar Packing Machine, etc.
- 大尺寸封装设计
- 制作枕头袋,插角袋,底部袋
- 这是一个庞大的巨型散装袋,为大型行李箱提供自动化解决方案,一次行程的尺寸长达18.9英寸,宽度为21.2英寸。
特征
- 单行程包长度可达480毫米(3.9至18.9英寸);袋宽可达535mm(4.7至21.1'')
- 真空泵有助于胶片输送
- 胶片自动跟踪,由光电传感器和编码器注册的长度
- 带有气动轴承座的胶卷支架
- 用支撑板缓冲重袋的下落
- 完全互锁的防护系统
- 坚固耐用的设备,可承受恶劣环境
附加信息
- 包袋样式:枕头袋
- 袋宽:200至550毫米
- 袋长:100至800毫米
- 产品特性:颗粒,粉末,液体,糊状物
- 加液系统兼容:容量杯,活塞填料,线性秤,多头秤,俄歇填料
- 跑步动作:间歇性
- 工作效率:5-30包/分钟
- 控制方式:带HMI触摸屏的PLC
- 日期编码可以是:烫印编码器,热转印编码器,标签施加器
- 可选配件:穿孔,吸尘,密封PE膜,SS框架,SS和AL结构,氮气冲洗,咖啡阀,空气排出器,重袋,加热和混合料斗
- 功率和电压:6 KW
- 压缩空气:0MPa 0.5M3 / min
- 尺寸:2400 * 1800 * 2750mm(94.5 * 70.9 * 108.3“)
- 机器重量:1200 KGS
我们热情的服务
1.您可以使用机器安装,调整,设置和维护的手册/视频。
2.如果发生任何问题并且您无法找到解决方案,可在24小时左右获得电信或在线面对面交流。
如果您同意支付支出,石龙工程师和技术人员随时准备为您的国家提供服务。
4.机器有一年保修。在保修期内,如果任何部件因误操作而未损坏,我们保证免费更换。机器发出后我们会收到提单,保修将开始计算。
石龙拥有一支独立的售后服务团队。如有任何紧急情况,请致电销售员或我们的售后经理
